PTP 850GP is a highly-flexible, compact, high-performance indoor unit that delivers multi-Gbps radio capacity. It extends reliable connectivity from small cells to major aggregation sites—reducing deployment complexity and accelerating time to revenue.
PTP 850GP
Specifications
RADIO
Interfaces
2 x SFP+ radio interfaces
2 x SFP+ dual-use radio or Ethernet interfaces (1/10G)
Supported RFUs
RFU-D, RFU-D-HP, RFU-SX
Features (RFU-SX)
1+0, 2x 1+0, 2+0, 1+1 HSB
Features (RFU-D/RFU-D-HP)
8+0, 4+0, 2 x 4+0, 2+0, 2 x 2+0
Space Diversity (RFU-D/RFU-D-HP)
Up 4+0 SD, up to 2 x (2+0) SD, 1+1 and 2+2 HSB-SD
High Spectral Use: QPSK to 2048 QAM w/ACM
XPIC option with all configurations
ETHERNET
Interfaces
6 x SFP+ (1/10G)
2 x SFP28 (1/10/25G)
2 x SFP+ Dual Use Radio or Ethernet Interfaces (1/10G)
1 x RJ-45 Management/Protection Interface (100M)
Management Interface
1 x 10/100 Base-T (RJ-45)
Ethernet Features
VLAN add/remove, MSTP, ERP (ITU-T G.8032), Y.1731 Ethernet OAM, Y.1731 Ethernet Bandwidth Notification (ETH-BN)
MTU
9600 Bytes
QoS
QoS classification based on TOS/DSCP, VLAN ID, VLAN P-bits, MAC DA and SA, SA and DA IP Addresses (IPv4 and IPv6)
Networking Capacity
193 Gbps
Management Protocols
SNMP, REST
SDN Support
NETCONFIG/YANG
TECHNICAL
Dimensions
44 mm x 428 mm x 156 mm
Weight
3 kg
Environmental
IDU: -5°C to +45°C; RFU: -33°C to +55°C
