ePMP 4500 / 4500C / 4500L 5 GHz Fixed Wireless Access Point

Cambium Networks’ ePMP™ product line has set the standard for high performance, scalability, and reliability in harsh interference environments, all at a compelling price. ePMP 4500 Access Points (AP) interoperate with Force 400 Subscriber Modules (SM) and support backward compatibility to Force 300 SMs. A sophisticated scheduling and QoS engine, combined with TDD synchronization, allows ePMP 4500 APs to deliver consistently high-quality service plans to a large number of end users.

ePMP 4500 Series 5 GHz Fixed Wireless Access Points

Cambium Networks’ ePMP product line has set the standard for high performance, scalability and reliability in harsh interference environments, all at a compelling price. The ePMP 4500 Access Point series is the fourth generation based on 802.11ax technology. ePMP 4500 Access Points series interoperate with Force 4500 Subscriber Modules. A sophisticated scheduling and QoS engine combined with TDD synchronization allows the ePMP 4500 Access Point series to deliver consistently high-quality service plans to a large number of end users.

Key Specifications

  • Checkmark High-performance, scalable and reliable access points for fixed wireless broadband
  • Checkmark Features MU-MIMO for up to 4 Gbps in 5 GHz
  • Checkmark Available in 3 options: Integrated 90-degree Sector (4500) and Connectorized (4500C and 4500L)
  • Checkmark Low TCO with three-year hardware warranty
  • Checkmark Interoperable with all Force 4500 radios
  • Checkmark Cloud or on-premises network management with cnMaestro

Cambium Networks 4500 AP Performance Demo

What's in the Box and How to Install

ePMP 4500 ePMP 4500L ePMP 4500C

ePMP 4500 / 4500C / 4500L 5 GHz Fixed Wireless Access Point

Specifications

Channel Spacing
Configurable on 5 MHz increments
4500 ROW Frequency Range
4920–6180 MHz
4500 FCC/IC Frequency Range
5180–5885 MHz
4500C ROW Frequency Range
4920–6180 MHz
4500C FCC/IC Frequency Range
5180–5885 MHz
4500L ROW Frequency Range
4920–6180 MHz
4500L FCC/IC Frequency Range
4920–5885 MHz
Channel Width
20 | 40 | 80 MHz
MAC (Media Access Control) Layer
Cambium Proprietary
Proprietary Physical Layer
ePMP 4500 and 4500C 8x8 MU-MIMO/OFDMA based on 802.11ax underlying technology. ePMP 4500L 2x2 MIMO/OFDMA based on 802.11ax underlying technology
ARQ
Yes
Nominal Receive Sensitivity (w/FEC) @20 MHz Channel
MCS 0 = -91 dBm to MCS 13 (4096 QAM-5/6) = -62 dBm (per chain
Nominal Receive Sensitivity (w/FEC) @40 MHz Channel
MCS 0 = -88 dBm to MCS 13 (4096 QAM-5/6) = -59 dBm (per chain)
Nominal Receive Sensitivity (w/FEC) @80 MHz Channel
MCS 0 = -85 dBm to MCS 13 (4096 QAM-5/6) = -57 dBm (per chain)
