ePMP Force 300-19R

Specifications

SPECTRUM

Channel Spacing
Configurable in 5 MHz increments
Frequency Range
Wide Band Operation 4910 - 5970 MHz (Note: Allowable frequencies and bands are dictated by individual country regulations.)
Channel Width
5 / 10 / 20 / 40 / 80

INTERFACE

ARQ
Yes
Nominal Receive Sensitivity (w/FEC) @20 MHz Channel
MCS0 = -89 dBm to MCS8 (256 QAM-3/4) = -68 dBm (per chain)
Nominal Receive Sensitivity (w/FEC) @40 MHz Channel
MCS0 = -87 dBm to MCS9 (256 QAM-5/6) = -66 dBm (per chain)
Nominal Receive Sensitivity (w/FEC) @80 MHz Channel
MCS0 = -84 dBm to MCS9 (256 QAM-5/6) = -61 dBm (per chain)
Modulation Levels (Adaptive)
MCS0(BPSK) to MCS9 (256 QAM-5/6)
Transmit Power Range
0 to +28 dBm (combined up to the regioanl EIRP limit) (1 dB interval)

SECURITY

Encryption
128-bit AES (CCMP mode)

CERTIFICATIONS

FCCID
Z8H89FT0048
Industry Canada Cert
109W-0048
CE
EN 301 893 V2.1.1 (5.4 GHz), EN 302 502 V2.1.1 (5.8 GHz)**
