How are people using Bridge-in-a-Box?

  • Extending Internet Connectivity
  • Connecting Remote Wi-Fi hotspots
  • Remote camera or CCTV video feeds

What is Bridge-in-a-Box?

Thousands of small businesses and residential users are using Bridge-in-a-Box to wirelessly extend their networks by simply connecting point A to point B. Each Bridge-in-a-Box comes with two wireless radio modules and power supplies that can be used to extend your network from wherever you have an Ethernet port to wherever you need one from 50 feet to 5 miles away (20 meters to 8 kilometers).  The modules are extremely easy to deploy as they come pre-configured and pre-paired to connect.

For those places you couldn’t connect before, Bridge-in-a-Box will get you there today.

What are people connecting with Bridge-in-a-Box?

  • Machine Shops / Garages / Storage Sheds / Docks / Boat Ramps
  • Any remote or outlying buildings
  • Remote parking lots
  • Campus Buildings
  • Building to Building
  • Cabins and Lodges
  • Construction Sites
  • Temporary Events such as Concerts, Farmers Markets, etc.
  • Athletic Fields and Events

Where can I buy Bridge-in-a-Box?

Have questions, need install advice or would like to help?

Visit the Cambium Community!

Handy guide to installing your new Bridge-in-a-Box modules

Bridge-in-a-Box

Specifications

Features

Wireless Standard
ePTP proprietary protocol. Supports longer ranges, lower latency, and greater performance. Optional Standard Wi-Fi mode of operation available.
Wired Interface
Gigabit / Fast Ethernet
Functions
Traffic prioritization using ePMP QoS (Quality of Service), WEP security.

Spectrum

Frequency Range
4910 – 5970 MHz
Channel Spacing
Configurable on 5 MHz increments
Frequency Range
5 GHz: 4910 – 5970 MHz (exact frequencies as allowed by local regulations)
Channel Width
5 | 10 | 20 | 40 MHz

Performance

ARQ
Yes
Nominal Receive Sensitivity (w/FEC) @20MHz Channel
MCS0 = -93 dBm to MCS15 = -72 dBm (per branch)
Nominal Receive Sensitivity (w/FEC) @40MHz Channel
MCS0 = -90 dBm to MCS15 = -69 dBm (per branch)
Quality of Service
Three level priority (Voice, High, Low) with packet classification by DSCP, COS, VLAN ID, IP & MAC Address, Broadcast, Multicast and Station Priority

Physical

Weight
0.50 kg (1.1 lb.) (includes mounting bracket)
Dimensions (h x w x d)
12.4 x 25.1 x 11.9 cm (4.9 x 9.9 x 4.7 in) – with mounting bracket attached
Wind Survival
145 km/hour (90 mi/hour) with antenna
