Secure, Mission-Critical Wireless Backhaul for Commercial and Defense Networks
Cambium Networks’ proven wireless Point-to-Point (PTP) backhaul solutions are deployed worldwide to support mission-critical connectivity in the most demanding environments. From service provider and enterprise networks to government, public safety, and military communications, our PTP portfolio delivers high-capacity, low-latency performance with carrier-grade reliability. With FIPS 140-2 compliant security options and hardened designs built for extreme conditions, Cambium backhaul solutions provide secure, resilient links when performance and trust cannot be compromised.
cnWave 60 GHz
The V1000 Client Node is featured with wide-range, 80º beamforming for easy installation. Powered by 802.3af PoE, V1000 supports up to 2 Gbps with 1 Gbps in the uplink direction and 1 Gbps in the downlink direction.
The cnWave 60 GHz V2000 client node features a 2.5 GbE PoE input port as well as a 2.5 GbE PoE 802.3at output port for powering Wi-Fi access points or video surveillance cameras. This makes the V2000 especially well-suited to backhaul Cambium’s XV2 series of outdoor Wi-Fi AP’s.
Find out how to get a cnWave Starter Kit at a great low price! Extend the Network with Wireless Cambium Networks’ 60 GHz cnWave solution provides easy, fast and cost-effective wireless gigabit connectivity for edge access and/or high-capacity Wi-Fi backhaul for edge access solutions at a significantly lower TCO than fiber infrastructure. Service providers and…
Sub 6 High Capacity Backhaul
Field proven high reliable backhaul for small cell and critical infrastructure
The PTP 45700 Beam Steering ODU with integrated Smart Antenna provides electronic beamforming that allows for easy tactical installation and best-in-class interference mitigation in addition to the industry-leading spectral efficiency and processing capabilities of the PTP 700 family of products.
Licensed Microwave Backhaul
PTP 850C is next generation all-outdoor, multi-core unit. The PTP 850C has dual-core functionality enabling the system to operate up to 4 Gbps and deliver gigabit-plus capacity.
PMP 450 Backhaul family
Backhaul links are the vital infrastructure that connects the network. You need confidence that your solution will work under heavy demand, regardless of the conditions. Licensed and unlicensed point-to-point (PTP) solutions from Cambium Networks perform reliably so that you can focus on your business. The PTP 450b features up to 300 Mbps in a 40 MHz channel. Frequency range is 4.9 – 5.925 GHz.
Up to 300 Mbps in a 40 MHz channel. Frequency range is 4.9 – 5.925 GHz
Fit to comprehensive network with dynamic interference filtering
Both the 2x2 PTP 450v and 4x4 PTP 450v support up to 2x40 MHz of operating spectrum to deliver over 500 Mbps of data.
Both the 2x2 PTP 450v and 4x4 PTP 450v support up to 2x40 MHz of operating spectrum to deliver over 500 Mbps of data.
ePMP Backhaul Family
Combining the latest 802.llac Wave 2 technology and the field proven scalable performance of ePMP, the Force 300-19R delivers up to 600 Mbps of capacity. The Force 300-19R is a powerful yet affordable subscriber module compatible with the ePMP3000 Access Point and using the forward compatibility features also interoperates with the ePMP 2000 to ease the migration into the 802.llac Wave 2 technology. The Force 300-19R has a 19 dbi integrated antenna with a narrow beamwidth and reliable IP67 mechanics.
Cambium Networks’ ePMP Force 300-25 is designed to operate in high interference environments and provides superior throughput of over 500 Mbps of real user data.
Tower Switches
104 Gbps throughput, 8 PoE+ enabled ports, 8 10/100/1000 Mbps ports, 4 SFP+ Uplink ports
112 Gbps throughput, 16 PoE+ enabled parts, 16 10/100/1000 Mbps ports, 4 SFP+ Uplink ports
Feature Comparison |
||||||
 |
 |
 |
 |
 |
 |
|
|
ATTRIBUTES |
cnWave v3000 |
ePMP Force 425 |
ePMP F300 |
450b |
PTP 550 |
PTP 670 |
| Max Throughput (up to) | 3.6 Gbps | 1.0 Gbps | 600 Mbps | 300 Mbps | 1.44 Gbps | 450 Mbps |
| Spectrum Efficiency (bits/HZ/s) | 1.67 | 12.5 | 7.5 | 7.5 | 9 | 10 |
| Frequency Range (GHz) | 57 to 66 | 4.910 to 6.135 | 4.9 to 5.9 | 4.9 to 5.9 | 5.1 – 5.9 | 4.9 to 6 |
| Channel BW MHz | 2.16 GHz | 20/40/80 | 20/40/80 | 5/10/15/20/30/40 | 2x 20/40/80 | 5/10/15/20/30/40/45 |
| Channel bonding | Roadmap | No | No | No | Yes | No |
| Top Modulation | 16 QAM | 1024 QAM | 256 QAM | 256 QAM | 256 QAM | 256 QAM |
| Packets Processed per Second | 80,000 | 80,000 | 50,000 | 120,000 | 850,000 | |
| Integrated Antenna | 40.5 or 44.5 dBi | 25 dBi | 13/16/19/25 dBi | 17/24 dBi | 23 dBi | 23 dBi |
| Latency | < 1 ms | 3-6 ms | 3-6 ms | 3-5 ms | 3-6 ms | 1-3 ms |
| Tx Power | 19 dBm beam-forming | 28 dBm | 27 dBm | 27 dBm | 26 dBm | 27 dBm |
| Jumbo Frame | 4000 bytes | 1700 bytes | 1700 Bytes | 1700 Bytes | 1700 Bytes | 9600 Bytes |
| Online Spectrum Analyzer | No | Yes | Yes | Standby | Yes | Yes |
| DSO | No | No | No | No | No | Yes |
| Encryption | 128 AES | 128 AES | 128 AES | 128 AES | 128 AES | 128 & 256 AES |
| 1588 Timing & SyncE | 1588 (Roadmap) | No | No | No | No | Yes |
| QOS | 4 level | 3 level | 3 Level | 4 Level | 3 Level | 8 Levels |
| PoE output | Yes | No | No | No | No | Yes |
| SFP Fiber Port | Yes | Yes | No | No | Yes | Yes |
| TDD Sync | Yes | No | Yes | Yes | Yes | Yes |
| TDM T1/E1 | No | No | No | No | No | Yes |
| IP Rating | IP67 | IP67 | IP55 (F300-19R=IP67) | IP67 | IP67 | IP67 |
| Power Consumption | 30 W | 28 W | 12 W | 12 W | < 30 W | <30 W |
